– SiVArc V15.1 SIMATIC Visualization Architect (SiVArc) setting up HMI content based on STEP 7 user program. – SIMATIC Energy Suite CPU setup and use of energy consumption monitoring devices like PAC3200 and others – Safety V15.1 frequency converters Step7 for programming FF S7-300F, S7-400F, S7-1200F and S7- 1500F, ET200F CPU – V15.1 processor configuration and use of Sinamics – WinCC V15.1 visualization environment for panels and computers – RAM: 16 GB or more (32 GB for large projects) – Processor: Intel® Core ™ i5-6440EQ (up to 3.4 GHz) – Windows 10 Professional / Enterprise (圆4 ONLY) You can provide enough documentation for all parts of the code, and archive these explanations and documentation regularly with the features the program provides, so that you can use it later to remember the logic of the program when browsing the project. You can also troubleshoot and correct applications written by others for PLCs by Siemens SIMATIC TIA. The PLC is a smart computer that you can access all of its components through the Simatic TIA Portal program and configure and test them in various modes during the simulation and programming process.
After coding, you can use a powerful simulator to run various tests on the written program to ensure it is working properly.
Using Step 7, coding can be done by moving and using graphical blocks, which will make the writing process easier. For this purpose, Siemens has developed the optimal Step 7 language, which is also used in this program. What this program does is to plan the logic of these PLCs for how to process the input data and what to do in the output.
In short, a PLC is a hardware interface that first reads data from digital inputs from passive sensors, then processes it as programmed into memory, and finally uses hardware controllers and output commands.
Simatic TIA Portal is a Siemens software application for programming and working with PLCs.
